| Place of Origin: | MADE IN CHINA |
| Brand Name: | ANG |
| Certification: | CE,ROHS |
| Model Number: | CM900 |
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | depend on |
| Packaging Details: | 1pc per box |
| Delivery Time: | 5-8 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 pieces per year |
| Material: | ABS | Size: | 172*87*125mm |
|---|---|---|---|
| Interface: | Type C | Communication: | Bluetooth |
| Weight: | 400g | IP: | IP52 |
| Frequency: | 860~960MHz |
| Physical Parameter | |
| Size | 172*87*125mm |
| Weight | 400g(including battery) |
| Configurations | UHF RFID / UHF RFID & scanning |
| Notification | Warning Tone, Multi-color LED |
| Battery | Li-polymer, 5700mAh |
| removable, 3.8V | |
| Up time: 8 hours Standby time: 300 hours | |
| Interface | Type-C |
| Conmunication | Bluetooth |
| Keypad | Power switch, scan keys |
| Modem switch, Bluetooth switch | |
| Power adaptor | Input: 100-240V, 50/60HZ, 300mA |
| Output: 5V, 2A |
| RFID Parameter | |
| UHF Solution | IMPINJ R2000 |
| Standards Supported | ISO18000-6C / EPC C1G2 |
| Fastest Read Rate | 200+ tags/sec |
| Reading distance | 10m (depending on label and antenna) |
| Frequency Range | CN:920-925MHz |
| US: 902-928MHz | |
| EP: 865-868MHz | |
| JP: 916-921MHz(wLBT) | |
| JP:916-923MHz | |
| Batch Mode Memory | Store 100,000+ RFID tags |
| Working Environment | |
| Operating Temperature | (-4℉ to 122℉ or -20℃ to 50℃) |
| Humidity | 5% to 85%(non-condensation) |
| Drop Specification | Within operation temperature range, |
| it can withstand several drops from 3.9 feet / 1.2m | |
| height to the concrete ground | |
| Roll Specification | It can withstand 200 times of 1.6 feet / 0.5m rolls, |
| achieving and exceeding requirements in IEC roll standard | |
| Vibration | 4g SPK Sine(5Hz to 2KHz), |
| 0.04g2 / Hzrandomness(20Hz to 2KHz) | |
| 60 minutes per axle, 3 axles | |
| Thermal Shock | (-40℉ to 140℉ / -20℃ to 60℃ fast fade) |
| Electrostatic Protection | (+/- 10kv air discharge, +/- 8kv contact electricity) |
| IP | IP52 |
| Data Collection | |
| Barcode Scanning | optional |
| Bluetooth | Bluetooth Class 1 |
| Bluetooth 4.1 | |
| Certification | CE/CCC/UN38.3/RoHS/IP52 |
| Accessories | Power adapter/USB cable/Battery |
| Optional Accessories | Multiple Charging Cradle/Universal Bracket |
